High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty

The Quality Of Crane We Bought From Henan Jinong Hoisting Machinery Co., Ltd Is Pretty Good , They Have Been Working Last Three Years Till Now, We Are Very Satisfied.

—— Kristie

I'm Online Chat Now

High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty

High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty
High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty

Large Image :  High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty

Product Details:

Place of Origin: China
Brand Name: Jingong
Model Number: CE

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: container
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detailed Product Description
Warranty: 12 Monthes Arm Length: 8m~70m
Condition: New Place Of Origin: China
Application: Port Structure: Steel
Working Duty: A3-A8 Material: Aluminium
High Light:

port material handling equipment

,

portal gantry crane

Standard Steel Structure Dry Prot Sea Port River Port Container Gantry Cranes



Product Description



Our crane is composed of gantry, lifting trolley, crane travelling mechanism, cab and electric control system. The gantry is of boxed-shape structure, the girder is bias track double girder and the leg is Type U.
It is suitable for loading and unloading of large span, frequently railway freight yard, port, open storage, container transfer station etc.. This machine adopts U type gantry, its legs headroom large.



Mechanical feature


Double welding box girder, DIN/FEM standard deflection
Steel tube legs
Material Fe37 or Fe52
Whole length CNC cutting for complete web plate, high deflection accuracy
High quality automatic welding and NDT inspection
Shot-blasting Sa2.5 for complete girder after welding, stress release
Epoxy zinc rich high quality painting, 2x2 with 140μm
10.9 class High tension bolts mounting between girder and legs, life time safety connection
Vertical gear motor driving,more safety and smaller space
High protection class IP55, F class, 40% ED
End carriage equipped with anti-friction bearings,cellular buffers,derailment protectors
Cabin Control
Easy operation
Professional chairs, adjustable and fully turning
Round window, big view
Two steps push button or joy stick station with emergency stop



Safety feature



1. Automatic rectify deviation control

2. Weight overload protection device

3. Top quality polyurethane buffer

4. Phase protection

5. Lifting limit switch,cross traveling limit switch,long traveling limit switch

6. Voltage lower protection function

7. Emergency stop system

8. Current overload protection system

9. Lighting system

10. Audio and video alarm system





Delivery Time



• Design and Installation Boat Lift, Small Boat Crane delivery :

• 180days for production, the port loading and custom cost about 6 days,
• the sea transportant takes 15days to 35days, the loading, transport and installation takes about 10days to 20days

• Total time: 210days to 241days



High Cargo Efficiency Port Crane Standard Steel Structure With 12 Months Warranty 0



Packing & Delivery

1. Delivery time :90 Days after receiving the deposit.
2. Packaging :
1). Wooden case for electric parts,motor,accessories, color cloth for main structure.
2). All parts will be loaded into 20ft or 40ft ISO container
all parts will be loaded onto Bulk Cargo Ship after package if the length is beyond 12.0m length is beyond 12.0m.
3. Transportation : generally 35 days to 60days to destination port.
4. Trade term : FOB, CFR and CIF are common trade terms, if you need more help, please ontact with Trade Consultant.



After Sales Services:



1.Payment terms is flexible.
2.Design the crane according to your technical request.
3.Delivery on time.
4.Our engineer can arrive to the installation site to help fixing the crane for you.
5.Warranty:12 months.
6.Providing free quick-wear part.
7.Low charge for continue maintenance when warranty is expired.
8.Exclusive engineer support at any time.



Installation service:



We have professional installation teams and rich installation experience,if you need,we can offer you overseainstallation service.



FAQ



1. Is your products customized?

Yes. We can provide the customized gantry crane depending on your detail requirement.



2. Can this type work in hazardous environment?

This gantry crane is just for application in general manufacturing work area. Crane for hazardous

environment, please consult our professional sales manager.



3. Do your side can provide other lift tools?

Yes, we can provide some lift tools like grab, hoist and electric magnetic chuck as you want.



4.The space of my workshop is limited, can the crane ok for mine?

Yes, please let us know your requirement and we engineer can design for you.
