Product Details:
|
| Product Name: | Empty Container Handler | Keywords: | Empty Container Stacker |
|---|---|---|---|
| Load Capapcity: | 8000kg 9000kg | Max Stacking Layer: | 6 , 7 , 8 |
| Max. Lifting Height: | 10825-19190mm | Power Souce: | Diesel Engine |
| Certification: | ISO9001 | Application: | 20'/40'/45' Containers |
| High Light: | Automated Guided Carts anti explosion,Mining transport Automated Guided Carts,Mining transport AGV Carts |
||
8 Ton 9 Ton Empty Container Handler For Stacking And Transferring ISO Standard Container
Empty Container Handler Introduce:
Empty Container Handler also named as Empty Container Stacker has simple structure, flexible control, good fretting and high explosion-proof safety performance. It is suitable for operations in narrow passages and limited spaces, and is an ideal equipment for palletizing in high-bay warehouses and workshops. It can be widely used in petroleum, chemical, pharmaceutical, textile, military, paint, pigment, coal and other industries, as well as ports, railways, freight yards, warehouses and other places containing explosive mixtures for loading and unloading, stacking and handling operations. It can greatly improve work efficiency, reduce the labor intensity of workers, and win market competition opportunities for enterprises.
Empty Container Handler Parameter:
|
Parameter |
Unit |
XCH908K |
|
|
engine |
Model |
- |
VOLVO TAD851VE |
|
Rated power/speed |
kW/rpm |
185/2200 |
|
|
Maximum torque/speed |
Nm/rpm |
1160/1350 |
|
|
Exhaust emission standards |
- |
3 stages |
|
|
Gearbox model |
- |
DANA 13.7HR32334 |
|
|
Drive axle model |
- |
Kessler D81PL488 |
|
|
Spreader |
Model |
- |
XDJ90 |
|
Side shift distance |
mm |
600 |
|
|
Self-respect |
t |
4.7 |
|
|
Suitable |
- |
ISO 20’/40’ container |
|
|
Tires |
- |
14.00-24-28PR |
|
|
Optional configuration |
Tire pressure monitoring system, Bromma spreader, TE14 gearbox |
||
Empty Container Handler Scope Of Use:
Developed for stacking and transferring ISO 20’-40’ standard container, rated load capacity 8t,9t. Can be used for port, storage yard, land port and logistics enterprise.
Empty Container Handler Photos:
