Product Details:
|
| Product Name: | Empty Container Handler | Keywords: | Empty Container Stacker |
|---|---|---|---|
| Load Capapcity: | 8000kg 9000kg | Max Stacking Layer: | 6 , 7 |
| Max. Lifting Height: | 16m | Power Souce: | Diesel Engine |
| Feature: | Good Fretting And High Explosion - Proof | Advantage: | High Operating Efficiency |
| Certification: | ISO9001 | Application: | 20'/40'/45' Containers |
| High Light: | Explosion Proof empty handler machine,Fretting empty handler machine,empty container stacker 0.60M/S |
||
Good Fretting And High Explosion - Proof Empty Container Handler High Operating Efficiency
Empty Container Handler Information:
The empty container stacker has a simple structure, flexible control, good fretting, and high explosion-proof safety performance. It is suitable for working in narrow passages and limited spaces, and is an ideal equipment for high-bay warehouses and workshops.
Empty Container Handler Applications:
It can be widely used in petroleum, chemical, pharmaceutical, textile, military, paint, pigment, coal and other industries, as well as in ports, railways, freight yards, warehouses and other places containing explosive mixtures for loading, unloading, stacking, and handling operations. It can greatly improve work efficiency, reduce the labor intensity of workers, and win market competition opportunities for enterprises.
Empty Container Handler Parameter:
|
Model |
|
DG90/8 |
DG90/7 |
DG80/7 |
DG80/6 |
|
Load capapcity |
kg |
9000 |
9000 |
8000 |
8000 |
|
Max stacking layer |
|
8 |
7 |
7 |
6 |
|
Lift speed loaden/unloaden |
m/s |
0.55/0.60 |
0.55/0.60 |
0.55/0.60 |
0.55/0.60 |
|
Lowering speed load/unload |
m/s |
0.60/0.60 |
0.60/0.60 |
0.60/0.60 |
0.60/0.60 |
|
Travel speed loaden/unloaden |
km/h |
26/28 |
26/28 |
25/27 |
25/27 |
|
Climbing abilty load/unload |
km/h |
38/- |
38/- |
30/- |
30/- |
|
Tractive force |
KN |
157.5 |
157.5 |
107.5 |
107.5 |
|
Dimension |
|||||
|
Wheelbase |
y(mm) |
4520 |
4520 |
4020 |
4020 |
|
Height of mast,lowered |
h1(mm) |
12399 |
11111 |
11091 |
9600 |
|
Tilt angle(forward/backward) |
a/b(°) |
3/4 |
3/4 |
3/4 |
3/4 |
|
Height of mast,extended
|
h4(mm) |
21818 |
192444 |
19204 |
16660 |
|
Height of cabin |
h6(mm) |
4326 |
4326 |
4326 |
4326 |
|
Height operator's seat |
h7(mm) |
3226 |
3226 |
3206 |
3206 |
|
Twistlock height,lowered |
h13(mm) |
2290 |
2290 |
2290 |
2290 |
|
Lift height |
h3(mm) |
21216 |
18642 |
18600 |
16290 |
|
Overall length |
l1(mm) |
6850 |
6850 |
6450 |
6450 |
|
Length to spreader face |
l2(mm) |
6682 |
6682 |
6277 |
6277 |
|
Overall width |
b1/b2(mm) |
4120/2570 |
4120/2570 |
3267/2398 |
3627/2398 |
|
Width of spreader 20'/40' |
b3(mm) |
6050/12150 |
6050/12150 |
6050/12150 |
6050/12150 |
|
Turning radius |
Wa(mm) |
6300 |
6300 |
5700 |
5700 |
|
Wheelspan,Front wheels |
b10(mm) |
3280 |
3280 |
2880 |
2880 |
|
Wheelspan,Rear wheels |
b11(mm) |
2171 |
2171 |
2068 |
2068 |
|
Weight |
|||||
|
Services weight |
kg |
38680 |
38280 |
33800 |
32800 |
|
Alex load with load,front/rear |
kg |
37220/10450 |
36610/10670 |
29050/10750 |
28650/10150 |
|
Alex load without laod,front/rear |
kg |
22660/16020 |
22480/15800 |
20100/13700 |
19700/13100 |
|
Engine |
|||||
|
Model |
DG90 |
DG80 |
|||
|
Engine manufacture/type |
Cimmins/QSB6.7 |
Cimmins/QSB6.7 |
|||
|
Cylinder number/displancement |
6/6700cm3 |
6/6700cm3 |
|||
|
Rated power |
164kw/2200rpm |
129kw/2200rpm |
|||
|
Maximum torque |
949nm/1500rpm |
800nm/1500rpm |
|||
|
Rated current of altemator |
100A |
70A |
|||
|
Battery |
24V(2x12/110) |
24V(2x12/110) |
|||
|
Transmission |
|||||
|
Model |
DG90 |
DG80 |
|||
|
Manufacturer/type |
ZF/3WG211 AUTO |
ZF/3WG211 AUTO |
|||
|
Clutch-type |
Torque Converter |
Torque Converter |
|||
|
Transmission |
Auto-shift/Interlock |
Auto-shift/Interlock |
|||
|
Gear number |
3F/3R |
3F/3R |
|||
|
Brake system |
|||||
|
Service brake:Wet-disc |
|||||
|
Packing brake:Brake enabled when power of |
|||||
|
Drive Axle |
|||||
|
Model |
DG90 |
DG90 |
|||
|
Driver axle manufacturer |
KESSLER/Germany |
KESSLER/Germany |
|||
|
Type |
D81PL488-NLB |
D81PL478-NLB |
|||
|
Steer Axle |
|||||
|
Model |
DG90 |
DG80 |
|||
|
Steering axle Manufacture |
OMCI/Italy |
OMCI/Italy |
|||
|
Type |
ASF |
Z16A1 |
|||
|
Steering type-Single cylinder |
Double action cylinder |
Double action cylinder |
|||
|
Tyres |
|||||
|
Drive wheels |
14.00-24 28PR |
14.00-24 28PR |
|||
|
Steering wheels |
14.00-24PR |
14.00-24PR |
|||
|
Type |
Pneumatic type |
Pneumatic type |
|||
|
Pressure |
10 bar |
10 bar |
|||
|
Quantity,Front/Rear |
4/2 |
4/2 |
|||
|
Spreader |
|||||
|
Model |
Self made |
Self made |
|||
|
Side shift distance |
+/-600mm |
+/-600mm |
|||
|
Working pressure for attachments |
140bar |
140bar |
|||
|
For handing |
20'or40'ISO standard container |
20'or40'ISO standard container |
|||
Empty Container Handler Photos:
