8t 9t 10 Ton 15ton Empty Container Handler For Narrow Passages And Limited Spaces
Empty Container Handler Information:
Empty container stacker is the key equipment for container transportation. It is widely used in the stacking and transshipment of empty containers in ports, wharfs, railway and road transfer stations and storage yards. , high operating efficiency, flexibility, space saving and other characteristics.
On the market, there are empty container stackers with a lifting height of up to 20m, stacking 9 layers and a gantry height of 13m. The container stacker is flexible and reliable, and can be used for multiple purposes.
Empty Container Handler Applications:
It can be widely used in petroleum, chemical, pharmaceutical, textile, military, paint, pigment, coal and other industries, as well as in ports, railways, freight yards, warehouses and other places containing explosive mixtures for loading, unloading, stacking, and handling operations. It can greatly improve work efficiency, reduce the labor intensity of workers, and win market competition opportunities for enterprises.
Empty Container Handler Parameter:
|material transfer trolley cart
|15ton or customized
|steel, battery, electronics
|2000*3000*300mm or customized
|lithium battery or lead acid battery
|remote control,forward, back, left ,right, emergency stop.
|motor, 4 wheels, battery, electrical control box
|4,Polyurethane or rubber
|IP 44 or IP54(outdoor)
|railless. with rail can be customized
The frame is a frame structure welded by two rectangular tubes and longitudinal beams and several cross beams and table top panels. Generally, large channel steel is used as the longitudinal and transverse beams of the frame, and all the steel plates below the table top are welded into a grid shape, so that the frame is evenly stressed. The wheels are installed at both ends of the rectangular tube, effectively reducing the height of the table. To facilitate lifting, lifting holes are set on both sides of the flat car.
The weld groove shall comply with the provisions of GB985 and 986, and the weld appearance shall be free of visible defects (such as cracks, holes, solid slag inclusion, incomplete fusion, incomplete penetration, shape defects, etc.). The steel plate welding groove is machined, and the welding sequence and overall grinding correction process are formulated according to the structural characteristics. The whole welding process is fixed and welded under the platform and welding fixture to ensure that the shape is free of deflection and has sufficient bearing capacity and deformation resistance.
The service life of the battery track flat car shall not be less than 10 years. The coating of the storage battery track flat car shall be of well-known brands at home and abroad. Type and color of paint: primer shall be sprayed on the interior of closed metal structure. The outer surface of metal structural members shall be sprayed with primer, intermediate coat, finish coat and varnish, and the color of the finish coat shall be specified by the user. The painting process of the whole vehicle is excellent and durable.
The advantages of lithium battery transfer cart
1. Motor drive system
2. It adopts the electromagnetic brake motor and the planetary reducer as the overall driving scheme, featuring high precision, large torque, high transmission ratio, no noise and no maintenance.
2.Frequency conversion technology
Using frequency conversion technology, we can save about 20%-40% of the power cost budget, from slow to fast operation mode, greatly reducing the impact on the equipment and increasing the service life of the entire system.
All accessories are modular and do not require soldering, minimizing the additional cost of replacing the accessories.
Empty Container Handler Photos
