Customized Double Girder Overhead Bridge Crane 20 Ton

Customized Double Girder Overhead Bridge Crane 20 Ton
Customized Double Girder Overhead Bridge Crane 20 Ton Customized Double Girder Overhead Bridge Crane 20 Ton Customized Double Girder Overhead Bridge Crane 20 Ton Customized Double Girder Overhead Bridge Crane 20 Ton

Large Image :  Customized Double Girder Overhead Bridge Crane 20 Ton

Product Details:
Place of Origin: China
Brand Name: Bestaro
Certification: CE ISO9001:2015
Model Number: MH-20TON
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 10000-20000
Packaging Details: export package
Delivery Time: 10-15 working days

Customized Double Girder Overhead Bridge Crane 20 Ton

Description
Capacity: 20tons Working Class: A3
Hoist Type: Wire Rope Electric Hoist Lifting Height: 6-30 Meters
Span: 5-30 Meters Power Supply: 3-phase AC 220- 690V 50HZ
Material: Q235B/Q345B Protection Class: IP54/IP65
Highlight:

customized bridge girder crane

,

double girder overhead bridge crane

,

20 ton overhead bridge crane

Product Description:

What is a Gantry Crane?

A gantry crane is a type of crane commonly used for lifting heavy loads in outdoor and large open spaces. Unlike overhead bridge cranes, which are fixed in place, gantry cranes have a bridge supported by two or more legs that run along rails at the ground level, allowing them to move across a large area. They are widely used in ports, warehouses, factories, and construction sites, where heavy objects or containers need to be lifted and moved efficiently.

Main Components of a Gantry Crane:

  1. Bridge:

    • The bridge is the horizontal frame of the gantry crane that spans across the workspace. It holds the hoisting mechanism and runs on the support legs.

  2. Support Legs:

    • These are the vertical structures that support the bridge. The legs often have wheels or tracks that allow the crane to move horizontally across a defined area.

  3. Trolley:

    • A trolley is mounted on the bridge and moves along its length. It carries the hoist or hook and is responsible for moving loads horizontally across the crane's span.

  4. Hoist/Hooks:

    • The hoist is the lifting device that raises and lowers the load. It is typically mounted on the trolley and is powered by an electric motor.

  5. Rails:

    • The crane's support legs often run on tracks or rails, which provide stability and guide the crane's horizontal movement.



Technical Parameters:

Attribute Value
Type Gantry crane
Control system Remote Control, Wire Button Control
Span 5-30 Meters
Lifting height 6-30 Meters
Travelling speed 20-40m/min
Working temperature -20℃~+45℃
Working class A3
Material Q235B/Q345B
Color Customized
Warranty 24months


Types of Gantry Cranes:
Single Girder Gantry Crane:

This crane has a single horizontal beam (girder) that carries the load. It is suitable for lighter loads and smaller spans.

Double Girder Gantry Crane:

A double girder gantry crane uses two horizontal beams, providing greater lifting capacity and stability for heavier loads.

Semi-Gantry Crane:

A semi-gantry crane has one leg running on rails while the other side is supported on a fixed structure, such as a wall. It is typically used in constrained spaces.

Full Gantry Crane:

A full gantry crane has two support legs, each running on rails, providing full mobility and a larger range of lifting capacity.

Working Principle:
Lifting Motion:

The hoist mechanism raises and lowers loads. The hoist is driven by an electric motor, providing precise control over the lifting process.

Horizontal Movement:

The trolley moves along the length of the bridge, allowing the crane to position the load horizontally across the working area.

Crane Movement:

The support legs run on rails, allowing the entire crane to move horizontally across the site. This provides flexibility to cover a large working area.

Advantages of Gantry Cranes:
High Load Capacity:

Gantry cranes are capable of lifting very heavy loads, making them ideal for applications like shipping, industrial manufacturing, and construction.

Versatility:

They can operate without the need for fixed tracks or installations, making them adaptable for various outdoor environments and open spaces.

Efficient Operation:

With their ability to move both horizontally and vertically, gantry cranes allow for fast and efficient material handling.

Stability and Safety:

The design of the gantry crane provides excellent stability, even when lifting heavy or oversized loads.

Applications:
Ports and Shipping: Used for unloading and loading shipping containers and heavy cargo.

Factories and Workshops: Ideal for lifting heavy machinery or large production components.

Construction Sites: Used to move construction materials such as steel beams, concrete, or pre-fabricated structures.

Warehouses and Logistics: Employed in large warehouses to lift and move goods, especially in areas with heavy traffic or limited space.



FAQ:


Q: What is the brand name of the gantry crane?
Answer: The brand name of the gantry crane is Bestaro.

Q: What is the model of gantry crane?
Answer: The model of the gantry crane is MH.

Q: Where are the gantry cranes produced?
Answer: Gantry cranes are produced in China.

Q: What is the load capacity of the gantry crane?
A: The load capacity of a gantry crane depends on its model.

Q: Does the gantry crane have a remote control?
A: Yes, the gantry crane has a remote control.
