Product Details:
Place of Origin: Henan,China
Brand Name: Bestaro
Certification: CE ISO9001:2015
Model Number: BT-25T1
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: 6500-9500US$
Packaging Details: Export standard packaging
Delivery Time: 10-15 working days
Payment Terms: L/C, T/T
Supply Ability: 5000 sets per year

Large Mechanical Handling 25T Free Turn Trackless Transfer Cart For Moving Machine

Description
Name: 25t Battery Powered Transfer Trolley Keywords: Material Transfer Cart
Capacity: 0-25ton Type: Battery Powered
Structure: Box Type Control: Remote Control, Forward,back,left,right, Stop Etc.
Power: 1.1kw Or Customized Application: Factory, Warehouse, Production Line
Material: Steel Color: Red/yellow/blue, Customized
Powered By: Lithium Battery Or Lead Acid Battery Working Time: 5-6 Hours
Charge Time: 7-8 Hours Work Speed: 0-20m/min, Can Be Adjusted
Guaranteed: 1 Year Certification: CE,ISO9001:2015
Wheels Number: Four Turn: Free Turn

Large Mechanical Handling 25T Free Turn Trackless Transfer Cart For Moving Machine



The advantages of lithium battery transfer cart



Flexible Pathways: Unlike traditional conveyor systems or track-guided transfer carts, trackless transfer carts can operate on any flat surface. They can navigate through open spaces, aisles, or designated pathways without the need for fixed tracks. This flexibility allows for easy reconfiguration of the layout and adaptability to changing production or workflow requirements.



Safety Features: Trackless transfer carts are equipped with various safety features to ensure safe operation. These may include emergency stop buttons, safety limit switches, obstacle detection sensors, and audible or visual alarms. These features help prevent accidents and ensure the protection of personnel and equipment in the vicinity.



Control Systems: Trackless transfer carts can be controlled through various means, including pendant controls, wireless remote controls, or automated control systems. The control systems allow operators to start, stop, steer, and adjust the speed of the carts as needed. Some advanced models may also have programmable logic controllers (PLCs) that enable automated operations and integration with other material handling systems.



Maintenance and Power Source: Trackless transfer carts typically use electric power sources such as batteries or overhead power supply systems. The electric motors are generally low maintenance, providing efficient and quiet operation compared to traditional combustion engines. Battery-powered carts can be recharged easily, while overhead power supply systems provide continuous power during operation.



product name material transfer trolley cart
capacity 20ton or customized
main material steel, battery, electronics
size 3000*4000*400mm or customized
powered by lithium battery or lead acid battery
working time 5-6 hours
charging time 7-8 hours
control remote control,forward, back, left ,right, emergency stop.
main parts motor, 4 wheels, battery, electrical control box
Wheel 4,Polyurethane or rubber
IP grade IP 44 or IP54(outdoor)
type railless. with rail can be customized
guaranteed 1 year
color customized.
certificate CE& ISO9001:2015





Brief introductions





Sensors play a crucial role in the operation of electric trackless carts. They can include laser scanners, cameras, ultrasonic sensors, or LiDAR (Light Detection and Ranging) sensors, which help the cart detect obstacles, navigate around them, and ensure safe operation. These sensors gather data about the cart's surroundings and provide it to the control system for real-time decision-making.





The battery power trackless transfer cart is an alternative transfer cart for rail transfer cars. It overcomes many inconvenience of rail-type electric transfer carts. The trackless electric transfer carts can finish free-turning without rail in the workshop and workshop. There is no need to lay rails, so it does not affect traffic, does not hinder production, and the flat car is more flexible, the operation is more humanized.



Trackless transfer carts, also known as trackless transporters or self-propelled transfer carts, are material handling equipment used to transport heavy loads within industrial environments. These carts are designed to move without the need for fixed tracks or guides, offering flexibility and adaptability in material transportation. Here are some key characteristics of trackless transfer carts:





Characteristic:



1. The trackless transport cart has short braking distance, high safety, strong durability and reliability. The trackless electric flat car can travel in both directions and turn 360°, and is suitable for a variety of working conditions.

2.





Application:



1.Material Handling: Electric transfer carts are commonly used for the transportation of heavy materials within factories, warehouses, and construction sites. They can be used to move raw materials, finished products, equipment, and components between different workstations or storage areas.



2.Assembly Line Operations: Electric transfer carts can be utilized in assembly line operations to facilitate the movement of products or workpieces between different stages of the manufacturing process. This helps to improve efficiency and reduce manual handling requirements.



3.Logistics and Distribution: Electric transfer carts are employed in logistics and distribution centers for efficient and organized transportation of goods. They can be used to move pallets, containers, and other loads between loading docks, storage areas, and delivery trucks.



4.Versatility: Trackless transfer carts are highly versatile and can operate in various environments, including factories, warehouses, assembly lines, and outdoor yards. They can navigate both indoor and outdoor spaces, making them suitable for a wide range of applications.



5.Self-Propelled: These carts are equipped with their own propulsion systems, typically electric motors, which drive the wheels or drive wheels directly. This allows them to move autonomously without being towed or pushed by external means. Some trackless transfer carts may also have steerable axles to enable precise maneuverability.





Large Mechanical Handling 25T Free Turn Trackless Transfer Cart For Moving Machine 0Large Mechanical Handling 25T Free Turn Trackless Transfer Cart For Moving Machine 1Large Mechanical Handling 25T Free Turn Trackless Transfer Cart For Moving Machine 2
