Product Details:
|
| Advantage: | Safe, Stable, Easy Maintainence. | Limit Switch: | Included |
|---|---|---|---|
| Steel Track Recommend: | 43kg/m Or QU70 | Usage: | Factory,Steel Factory |
| Can Be Customized: | Available | Working Duty: | A3, A1-A8 Customized |
| Lift Height: | 6-30M | Load Capacity: | 5-800t |
| High Light: | Durable Double Girder Bridge Hanging Crane,hoists Double Girder Bridge Hanging Crane,High Efficiency double girder overhead crane |
||
The end trucks are located at each end of the crane and support the girders. They are equipped with wheels or rollers that allow the crane to move along rails or tracks. The end trucks also house the drive mechanisms, such as motors and gearboxes, that power the crane's movements.
A hoist and trolley assembly is mounted on the girders and is responsible for lifting and moving the load. The hoist is the lifting device that is attached to a trolley, which runs horizontally along the girders. The hoist and trolley system can be electrically or manually operated, depending on the specific requirements.
The double girder overhead crane is controlled through a control panel or pendant station. The control system allows operators to safely operate the crane, controlling its movements, lifting and lowering the load, and managing the speed and positioning of the crane.
Double girder overhead cranes are equipped with various safety features to ensure safe operation. These may include overload protection systems, limit switches to prevent over-travel, emergency stop buttons, safety brakes, and warning devices such as alarms or lights.
Longer Span:
Compared to single girder cranes, double girder overhead cranes are capable of spanning longer distances. Their double girder configuration allows for greater structural rigidity, enabling the crane to cover larger areas or workstations within a facility.
The double girder design also provides for a higher hook height, allowing for greater vertical lift and improved flexibility in handling taller loads. This makes them suitable for use in facilities with higher ceilings.
Double girder overhead cranes can be customized to meet specific application requirements. They can be tailored in terms of load capacity, span, lifting height, speed, and control options. This flexibility allows the crane to be optimized for various industrial sectors and unique operational needs.
| Technical Parameter | Value |
|---|---|
| Product Name | Double Girder Overhead Crane |
| Girder Type | Double Type |
| Capacity | 5-100 Ton |
| Load Capacity | 5-800t |
| Lift Height | 6-30M |
| Working Grade | A5-A7 |
| Usage | Factory, Steel Factory |
| Warranty | 18 Months |
| Guarantee Period | 12 Months |
| Can Be Customized | Available |
| Advantage | Safe, Stable, Easy Maintenance |
Double girder overhead cranes are essential equipment used in various industries and sectors for lifting and moving heavy objects during production processes and other operations. Their strong and durable design makes them suitable for handling heavy loads and operating in harsh environments. Below are some of the main applications of these cranes:
Double girder overhead cranes are commonly used in manufacturing facilities to lift and move heavy components, machinery, and equipment during production and assembly processes. These cranes are crucial in industries such as automotive, aerospace, steel, and general manufacturing.
In steel mills and metal processing plants, double girder overhead cranes play a vital role in handling molten metal, large steel coils, ingots, and other heavy materials. These cranes are designed to withstand high temperatures and harsh environments, making them ideal for use in these industries.
Double girder overhead cranes are also commonly used in construction sites and infrastructure projects for lifting and transporting heavy materials such as construction materials, precast concrete elements, and steel structures. These cranes help expedite project completion and increase productivity on site.
Brand Name: Bestaro
Model Number: BC-1D
Place of Origin: China
Certification: CE ISO
Minimum Order Quantity: 1 Set
Price: 10000-50000 USD
Packaging Details: Export Standard packing
Delivery Time: 15-45 days
Payment Terms: TT
Supply Ability: 500 Sets per month
Load Capacity: 5-800t
Advantage: Safe, Stable, Easy Maintainence
Working Grade: A5-A7
Limit Switch: Included
Can Be Customized: Available
Our crane is equipped with a limit switch to ensure safe operation and working grade ranging from A5-A7 for heavy duty applications. It can also be customized with various optional features to enhance its performance.
Trust Bestaro for all your overhead crane needs. Contact us now to get a quote and let us help improve your material handling efficiency.
